Maximum Lifting Capacity / Radius: 90 US-tons (81.6 t)

Main Boom: 39 – 164 ft (11.9 – 50.0 m) - 5 sections, locking and pinning ovaloid style boom.

Jib: Bi-fold, manual offset 20°/40°, 32.8 – 62.3 ft (10.0 m – 19.0 m)

Maximum Tip Height: 226 ft (69m)

GVW: 98,900 lbs (44,900 kg)

Carrier Engine: Detroit Diesel 13 12.8L 2010 EPA (450 hp /335 kW)

Transmission: Allison Transmission - Automatic, 6 Forward, 1 Reverse

Superstructure Engine: Daimler (175 hp / 130 kW)

Drive / Steer: 8 X 4 (optional tag axle available) inter- axle & differential locks standard.

Tires: Goodyear Front – 445/65R22.5 20 PR, Rear – 315/80R22.5 20PR

Optional Tag Axle – 445/50R 22.5

Maximum Counterweight: 57,500 lbs (26,082 kg)

Main & Auxiliary Hoists: 2 speed – 476 fpm (2.4 m/s) – 18 mm wire rope

Max Line Pull: 18,100 lbs (8,210 kg)

Features:

· X – Pattern swing out outriggers

· Class leading lifting capacities

· Fully automatic counterweight rigging system

· IC-1 control system

· Operator’s cab with variable 0-20° tilt, for excellent visibility to the load

· Electro –proportional joystick controls

· Standard remote outrigger controls

· Front stabilizer jack located behind cab

· Self-stowing outrigger pads

· Eleven standard tool cabinets

· Full ride air suspension

· Heat & Air Conditioner standard

SOLD
